01Manufacturing

Manufacturing Capability You Can Verify

Production takes place at the Ningbo site: tank moulding, motor machining, assembly, water testing, running-in and packing. The figures below are given with their measurement basis rather than as a single headline number.

Factory building exterior with loading area at the production site

02Scale

Plant figures and basis

Area and capacity are different measurements; they are kept separate so a figure is never read as output.

Plant area

12,000m²

According to company data

Building area

15,000m²

According to company data

Designed capacity, single line

80,000units / year

Design figure, not output. Consistency with published material to be confirmed

03Process

Six steps from part to carton

Each step happens on the same site; the sequence is the order used on the line.

01
Incoming inspection
Motor, impeller and tank parts are checked against the drawing before they enter the line.
02
Moulding and machining
Tank moulding and motor machining are carried out in-house on the same site.
03
Assembly
Pump, float control and electrical chamber are assembled and wired as one unit.
04
Water test
Each unit is run in a water bench to check flow, head and float switching.
05
Running-in
Units run for a set period to catch seal, noise and start-up faults before packing.
06
Packing
Carton, foam and manual are packed to the export loading quantity for each model.

04Quality

What is checked, and where

Incoming parts

Motor winding resistance, impeller dimensions and tank wall thickness are checked before assembly, per the factory inspection routine.

Water test bench

Each assembled unit is run in water to confirm flow, head and float switching before it leaves the line.

Running-in and packing

Units run for a set period to catch seal and noise faults, then are packed with manual and foam to the export quantity.

Water testing bench used to verify flow and head of assembled units — Water test bench

Cartons stacked in the warehouse before container loading — Packed stock before loading

Inspection records pending

Calibration documents and inspection record formats are released once the factory file is confirmed.

05Quality assurance

Certificates & Quality Assurance

Every scan below is the document as issued: logos, seals, numbers and issuing bodies are reproduced unchanged. All certificates are held by the manufacturing partner, not by the Anteloy brand.

Holder on every document

Ningbo Chixiang Electromechanical Tech Co., Ltd.

Documents published

4 confirmed · 2 awaiting a clearer copy

How to read them

Each scan is shown in full, at its original proportions. Particulars that are not legible on the supplied scan are marked pending instead of being transcribed, and clearer copies are available on request.

TÜV Rheinland CE certificate of conformity to the Low Voltage Directive 2014/35/EU, registration number AN 50565452 0001

CE Certificate of Conformity — Low Voltage Directive 2014/35/EU, pump unit

Holder: Ningbo Chixiang Electromechanical Tech Co., Ltd.
Issued by: TÜV Rheinland LGA Products GmbH, Nürnberg
Reference: Reg. No. AN 50565452 0001 · Report No. 50222304 005
Validity: Issued 16 November 2022. No expiry date is printed on the certificate.
Scope: Low-voltage conformity of the pump unit series. The model list covered by the certificate is printed in its Identification field, and the report number above refers to that evaluation.

TÜV Rheinland CE certificate of conformity to the Low Voltage Directive 2014/35/EU, registration number AN 50564126 0001

CE Certificate of Conformity — Low Voltage Directive 2014/35/EU, lifting station

Holder: Ningbo Chixiang Electromechanical Tech Co., Ltd.
Issued by: TÜV Rheinland LGA Products GmbH, Nürnberg
Reference: Reg. No. AN 50564126 0001 · Report No. 15060048 007
Validity: Issued 22 November 2022. No expiry date is printed on the certificate.
Scope: Low-voltage conformity of the lifting station series. The model list covered by the certificate is printed in its Identification field, and the report number above refers to that evaluation.

Test report cover page from the Shanghai Institute of Quality Inspection and Technical Research for sample type WL600A

Test report — WL600A sewage lifting device

Holder: Ningbo Chixiang Electromechanical Tech Co., Ltd. (applicant)
Issued by: Shanghai Institute of Quality Inspection and Technical Research
Reference: Report number and issue date are on the report body, not on the cover page held here
Validity: A test report carries no validity period. The cover page shows the sample, applicant and test purpose.
Scope: Commissioned test of sample type WL600A (sewage lifting device). The uploaded document is the cover page; the test items and results are listed in the report body.

The full report body is supplied with quotations and tender packages on request.

Test report cover page from the Shanghai Institute of Quality Inspection and Technical Research for sample type WL300A

Test report — WL300A sewage lifting device

Holder: Ningbo Chixiang Electromechanical Tech Co., Ltd. (applicant)
Issued by: Shanghai Institute of Quality Inspection and Technical Research
Reference: Report number and issue date are on the report body, not on the cover page held here
Validity: A test report carries no validity period. The cover page shows the sample, applicant and test purpose.
Scope: Commissioned test of sample type WL300A (sewage lifting device). The uploaded document is the cover page; the test items and results are listed in the report body.

The full report body is supplied with quotations and tender packages on request.

Intertek authorization to mark document for the ETL mark

Intertek authorization to mark — ETL

Pending

Holder: To be confirmed from the original document
Issued by: Intertek
Reference: ATU number, standard and model list are not legible on the uploaded scan
Validity: To be confirmed
Scope: Authorization to apply the ETL mark to listed products. The model list printed on the document has not been transcribed because the scan is not readable.

A clearer copy of this document is needed before the ATU number, covered standard and dates are published.

Four patent certificate covers held by the manufacturer, three utility model and one design patent

Patent certificates — three utility model, one design

Pending

Holder: Ningbo Chixiang Electromechanical Tech Co., Ltd.
Issued by: China National Intellectual Property Administration (certificate covers)
Reference: Certificate numbers, titles and dates are not legible on the uploaded photo
Validity: Per the term printed on each certificate
Scope: Four patent certificates photographed together: three utility model certificates and one design certificate.

Certificate numbers and titles are being transcribed from the originals before they are listed individually.

06Export

How the range is supplied

Two electrical platforms

50Hz and 60Hz units are produced as separate platforms with their own windings, so a market can be supplied without converting a 50Hz design.

Packing for container loading

Carton quantity, carton size and 20GP / 40GP / 40HQ loading are recorded per model and quoted with each order.

Documentation

Catalog, optional datasheet and certificate copies are released as each document completes verification.

Structure and service access

Water and electrical chambers are separated so the motor stays out of the wastewater volume; the float control, impeller and motor assembly are reachable without cutting the discharge line. Factory profile documents covering these points are being prepared for release.

Request Factory Profile Certifications

Ask for the current factory file

Ningbo Chixiang Electromechanical Tech Co., Ltd. · No.518 Yindong North Road, Yinzhou, Ningbo, China
